Ryzen 3 MOCK Build - it lives!

Tinkering
1

Having been sold on Roon within a couple of days of trying it I needed to do my bit for the planet and build a low power mini PC to run it on.

Being an AMD fan I specced up a Ryzen 3 3200G setup from Amazon for a few pence over £320 and was going to just run Roon Server headless over W10 or some Linux distro but having read about ROCK thought I’d at least give it a go.

What can I say. In a way I wish I could write a dozen paragraphs about all the clever little tweaks etc I had to make in order to get it to work. But, almost disappointingly it just worked.

A couple of sticking points was working out how to get the system to legacy boot and how to get into the data folder to add the codec. Other than that it installed in seconds and I’ve copied my database across etc and all is good.

For full disclosure I’ve not tried it via WiFi as I hardwire in whatever I can in the house. WiFi of course may present a slight challenge driver-wise.

Full bill of parts:

Ryzen 3 3200G
ASRock DeskMini A300 Mini PC Barebone for Socket AM4
8gb Crucial Memory SODIMM DDR4 module
Samsung 860 Evo 256gb SSD*
Noctua NH-L9a AM4**

*I did originally spec an Integral M Series 256GB NVMe M.2 which was due to come at the same time but then Amazon decided it wouldn’t be with me until May so I stuck the spare SSD in I had lying around.

**The barebones kit comes with a blown cooler bit by all accounts it’s a bit noisy but you could save yourself £30 odd by using it. Noctua make the best coolers though and I’ve no worries a) about noise or b) it overheating.

I would say as well the power supply the barebones box comes with is a nice proper linear transformer job and not some cheap switch mode thing but it does only come with a European plug and it’s one of those cloverleaf leads so you may need an adapter or another lead if you have one lying around.

Not much else to say about it really. All up and running very nicely and very happy with ROCK - a great solution :slight_smile:

image1280×958 256 KB
image3024×4032 3.28 MB
image1280×958 408 KB
image1280×958 304 KB
image1280×958 261 KB
image1280×958 300 KB
image1280×958 239 KB
image1280×958 422 KB
image1242×2688 273 KB

image1242×2688 571 KB

8 Likes
2

image1280×958 422 KB

I see it actually rocked your socks off! :sweat_smile:

3 Likes
3

Oh and note I nearly made the silly mistake of buying a Ryzen 5 3600 and putting that in my workstation and moving the older Ryzen 5 2600 in this.

Of course those chips don’t have onboard graphics so would have made it rather complicated to actually set the dammed thing up :slight_smile:

Make sure you get a G series chip if you try this!

1 Like
4

Glad to see you make a note of this as I forgot to mention the fact that most Ryzens dont have an GFX onboard

similarly there are no mentions of MOCK or Ryzen in the KB as most would all be using Windoze or Linux

5

As of my understanding, MOCK is ROCK on unsupported hardware.

We have worked with Intel to support their Intel NUC line of products. They are low power high performance easy to install units that work very nicely as a Roon Core Server. The models we support are:

  • NUC5i3xxx
  • NUC5i5xxx
  • NUC6i3SYx
  • NUC6i5SYx
  • NUC7i3BNx
  • NUC7i5BNx
  • NUC7i7BNx
  • NUC7i3DNx
  • NUC7i5DNx
  • NUC7i7DNx
  • NUC8i3BEx
  • NUC8i5BEx
  • NUC8i7BEx

Any hardware configurations other than the above are unsupported . Although they may work now, they may also stop working at any time due to updates.

Installing Roon on Windows or Linux (or Mac OS X) is described in the Roon User Guide.

6

Blockquote similarly there are no mentions of MOCK or Ryzen in the KB as most would all be using Windoze or Linux.

No reason not to use a Ryzen chip to run Windows or Linux. They’re just X86 processors and a very common alternative to Intel. I’ve been using them since the 90’s. I assume you more this anyway but just posting it in case others stumble on the thread.

I’ve always liked AMD processors so have just kind of stuck to them.

As per @BlackJack there’s no mention of them in the ROCK KB because Roon only officially support NUC based ROCK servers but NUC is an Intel thing.

That said there’s nothing special about them. They are just mini PC’s that have a pretty rigid specification so drivers etc are standard. But given this it’s quite straightforward for Roon to provide support for them.

Of course if it ever stops working I can just install W10 or whatever and Roon Server and have it run headless that way :slight_smile:

2 Likes
7

Sorry for the idiotic question but is Mock actually Rock installed on an unsupported pc? Also did you manage to get the ethernet up and running?
I tried Roon on Windows on a 4750G/X300 and it sounded fantastic … in allot of ways superior than NUC/Rock - but not all ways.
If the ethernet side of things worked allright…I am tempted to build a Mock/X300 …

8

If you start a new post in the tinkering category the techies who hang out there will help.
Yes mock is rock on non supported hardware.

9

Hi Mikael … I have an X300…so your post is amazing…
I tried Roon on Windows on a 4750G/X300 and it sounded fantastic … in allot of ways superior than NUC/Rock - but not all ways…on your install did you just go ahead and load rock straight on … un modified??? Does the ethernet work ok? have you tried an APU …to see if the HDMI works?
Found this great passive case…not cheap but rather well engineered…
